Classic Fuel Injection
Premium Vehicle Kit for vehicles fitted with American V8 engines using the common 4 barrel 4150 or " Square Bore " mounting.

This kit will suit many of the US V8 engines as fitted to Chevolet, GM, Ford and Chrysler vehicles
currently fitted with a 4 BBL carburettor.

This listing is for the 4 Injector version of this kit with 630cc Injectors fitted to support engines of around 440 BHP

( we can supply injectors 1100cc upto around 750 BHP select option if required )

The total height of the throttle body and the injector base plate is approx 80mm ( Body = 60mm, Plate = 20mm )
It will be lower / shorter than most 4 barrel carburettors it is replacing so bonnet clearance space should not be an issue.


Complete with an included adaptor this should fit any vehicle with the standard "Square Bore " inlet manifolds.
( if you source or make an adaptor plate then you should be able to also fit this kit to Spreadbore and Solex equipped vehicles such as Rolls Royce and some Mercedes - we cannot supply this plate as it would vary by vehicle )

This kit will support many " Small Block " and " Big Block " engines from around 4.0L upto around 8.0L.

We can support engine power from around 240 BHP all the way to 750 BHP depending on fuel injectors chosen.

You can also use this kit as a base for other V8 engines such as the Rover V8 but you may need to make changes to the adaptor and / or manifold

These Throttle Bodies are normally Silver in colour as per the photos but occasionally due to availability we have to supply the Black version.
Other than the colour they are exactly the same specification.

We cannot supply based on colour choice and orders will be fulfilled using the current stock.



This kit contains all the parts needed for our Classic Fuel Injection system
(you do not need to order anything else from our range )

This Premium kit will suit most V8 engines fitted with a 4 barrel carburettors.

This kit comes with a new 1000 CFM 4 barrel throttle body to support the common 4150 flange carbuettors.

Along with our custom adaptor plate that holds the Fuel Injectors and Fuel Rail with hosetails for Idle Air Control and MAP sensor this assemby replaces the existing carburettor and is normally a direct bolt on replacement to looks visually similar to the original carburettor.

We have assembled this kit for easy ordering but if you prefer you can still order some or all of the parts using our individual listings

Ordering our kits will also save you money, our kits are typically 10 to 15% cheaper than ordering individual parts


This kit contains

Engine ECU - Based on the MaxxECU MINI ECU
ECU software
ECU to Laptop communication lead

Engine Sensor Kit Comprising -
Throttle Position Sensor - Built onto the new V8 throttle body
Coolant Temperature Sensor
Manifold Absolute Pressure Sensor - inbuilt into the ECU
Distributor Sensor
Distributor Pickup
Ignition Amplifier
Idle Control Valve Module
Idle Control Valve Housing - Built onto the new V8 throttle body
Wide Band Oxygen Sensor Amplifier
Wide Band Bosch Oxygen Sensor
Weld On Oxygen Sensor Boss

Fuel System Kit Comprising -
High Pressure Fuel Pump
Fuel Pump Brackets
Inline Fuel Filter
Fuel Filter Bracket
Fuel Pressure Regulator
10m of High Pressure Fuel Hose
Fuel Hose Clamps

V8 Throttle Body and Adaptor Kit Comprising -
1000 CFM 4 Barrel 4150 Billet Throttle Body
Custom Adaptor Plate - Our Design, Unique to us !
4 x Fuel Injectors as selected assembled onto the new Throttle Body assembly
2 x Twin injector fuel rail - included with the throttle body and adaptor
TPS sensor built onto the Throttle Body
Gaskets and fitting



Electrical Wiring
Plug and Play wiring loom ready to install

Please note this kit does not contain nuts, bolts and other fixings or adapters as they will be specific to your application but will easily be sourced from your normal suppliers or your existing workshop stock of parts.
