Citroen DS, Citroen ID Classic Car Fuel Injection Conversion
Based on our Premium Vehicle Kit for Single carburettor upto 110 BHP with Custom DS wiring harness
Notes for Ignition Distributor
The 123 Distributor is probably not compatible.
Nor is the original DS EFI distributor ( it would work but not enough internal space to modify it )
We advise replacing the 123 or original DS EFI Distributor with an old " Ducelier " distributor from a non EFI DS and modify that for use with our kit
( Avoid the Citroen DS " SEV " Distributor, as it showed some problems on another DS and there is not a modification kit available)
Save around £200 when buying as complete kit
(compared to individual component prices)
We have assembled this kit for easy ordering but if you prefer you can still order some or all of the parts using our individual listings
Ordering our kits will also save you money, our kits are typically 10 to 15% cheaper than ordering individual parts
This kit contains
Engine ECU - Most of our systems are now based on the MaxxECU MINI ECU
ECU to Laptop communication lead
Engine Sensor Kit Comprising -
Throttle Position Sensor
Coolant Temperature Sensor
Manifold Absolute Pressure Sensor
Distributor Pickup for 4 cylinder
Idle Control Valve and housing
Wide Band Oxygen Sensor Amplifier
Wide Band Bosch Oxygen Sensor
Weld On Oxygen Sensor Boss
Fuel System Kit Comprising -
High Pressure Fuel Pump
Fuel Pump Brackets
Inline Fuel Filter
Fuel Filter Bracket
Fuel Pressure Regulator
10m of High Pressure Fuel Hose
Fuel Hose Clamps
Fuel Injector Kit Comprising -
1 x Siemens Fuel Injector for total engine power upto around 110 BHP
1 x Fuel Injector High Pressure Hose Fittings for Fuel Inlet
2 x Fuel Injector Mounting Plates
2 x M6 Mounting Plate Fixings
1 x Carburettor Adapters
1 x Carburettor Adapter Idle Air Take Hose Fittings
Single injector universal wiring loom ready to install
Please note this kit does not contain nuts, bolts and other fixings or adapters as they will be specific to your application but will easily be sourced from your normal suppliers or your existing workshop stock of parts.
Classic Fuel Injection Conversion, Citroen DS, Citroen ID Premium Kit
- Brand: Classic Fuel Injection
- Product Code: CFI-Kit Cit DS
- Availability: 99
IMPORTANT INFORMATION RELATING TO THE RETURN OF COMPLETE FUEL INJECTION VEHICLE KITS
The vehicle kits will normally be supplied with the ECU pre loaded with an initial start file.
This initial start file is simply provided as an aid for
engine starting, it should not be considered a suitable final
calibration for your engine.
You must be prepared to undertake further ECU calibration work to ensure the ECU files are tailored to your vehicle.
Failure to successfully complete the calibration process may lead to poor vehicle driveability or even damage to your engine.
Our Classic Fuel Injection Kits are custom built to order and to the customer general specification and as such are exempt from automatic return rights under Consumer Contract regulations.
By ordering this conversion kit you understand that further ECU calibration work will be required and the final results are outside of our control.
We cannot accept returns or claims arising from failure to successfully complete the calibration process.
